Description

Product Description

The BUSSMANN JJN-35 is a 35A, UL Class T fuse with very fast acting current limiting. With an AC voltage rating of 300V and an interrupting rating of 200,000 AIC RMS at 300VAC, this fuse provides excellent component protection. It is UL Listed and CSA Certified.

  • 35 Amps
  • 300 Volts AC
  • UL Class T Fuse

Product Highlights

The BUSSMANN JJN-35 fuse offers very fast acting and current limiting capabilities.

Product Information

Standard Information

  • Brand: BUSSMANN
  • Manufacturer Part Number: JJN-35
  • Country of Origin: Mexico
Technical Specifications
Amps
35
Volts AC
300
Fuse Class
T
Speed
Very Fast Acting
Current Limiting
Yes
Physical Size
0.56" x 0.88"
AC Voltage Rating
300 V AC
Interrupting Rating
200 kAIC at 300VAC
UL Listed
Std. 248-15, Guide JDDZ, File E4273
CSA Certified
C22.2 No. 248.15, Class 1422-02, File 53787
Product Length/Depth
0.88 in
Product Height
0.56 in
Product Width
0.56 in
Compliances
CE Marked RoHS Compliant
Product Type
Fuse
Amperage Rating
35 A
Interrupt rating
200 kAIC at 300 Vac 20 kAIC at 160 Vdc
Voltage rating
300 Vac, 160 Vdc
Packaging type
Standard
Connection
Ferrule end x ferrule end
Fuse indicator
Non-indicating
Series
JJN
Mpn
JJN-35
Upc
051712627351
Gtin
51712627351
Body Material
Melamine
Compatible Fuse Block Series
T300;
Current Rating
35 A
DC Voltage Rating
160 V DC
Element
Single
Fuse Body Style
Cylindrical
Fuse Block Style
Non-Rejection
Fuse Class or Type
T
Interrupt Rating - AC
200 kA
Interrupt Rating - DC
20 kA
Overall Diameter
9/16 in
Overall Length
7/8 in
Standards
CE/UL-248-15 Guide JDDZ/CSA Class 1422-02
Visual Indication
Non-Indicating
UNSPSC
39121608
Manufacturer
Eaton Bussmann
Brand
Eaton Bussmann Series
Country of Origin
Multiple
Made in USA
No
Application
Ind Facilities & Factories - Facility: Safety and Security Systems
Standard
CE Marked,RoHS Compliant
Item Type
Fuse
Weight UOM
Pounds
Size
0.56 In Diameter X 0.88 In Length
