Bussmann GMT-1/2A Telecommunication Fuse 0.50A

Product Description

The Eaton Bussmann series GMT-1/2A is a telecommunication fuse with a color code red. This fast-acting, non-indicating fuse is rated for 125 Vac and 60 Vdc with a 0.50A amperage rating. It features tin-plated beryllium copper terminals and is suitable for telecommunications DC power circuit protection.

• Color code red
• Non Indicating
• Fast-acting
• Tin-plated beryllium copper terminal

Product Highlights

The Bussmann GMT-1/2A fuse is ideal for telecommunication applications requiring reliable circuit protection.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: GMT-1/2A
• Country of Origin: Mexico

Technical Specifications

• Product Name: Eaton Bussmann series GMT telecommunication fuse
• Catalog Number: GMT-1/2A
• UPC: 051712576703
• EAN: 5027590093101
• Product Length/Depth: 0.78 in
• Product Height: 0.62 in
• Product Width: 0.11 in
• Product Weight: 0.1 lb
• Compliances: CE Marked RoHS Compliant
• Product Type: Telecommunication fuse
• Amperage Rating: 0.50A
• Voltage rating: 125 Vac, 60 Vdc
• Packaging type: Standard
• Fuse indicator: Non-indicating
• Special features: Color code red
• Amperage: 1/2 Amps
• Voltage: 125 Volts AC/60 Volts DC
• Fuse Type: Telecom Protection Fuse
• Speed: Fast Acting
• Body Material: Thermoplastic
• Rejection: Non-Rejection
• Interrupting Rating: 300A @ 125vac, 450A @60vdc
• Physical Size: 13/16" Length
• Alternate Mfr Part Number: BK/GMT-1-2A
• Application: Telecommunications DC power circuit protection
• Brand: Bussmann by Eaton
• Dimensions: 0.62 in H X 0.11 in W X 0.78 in L
• Mounting Type: Clip
• Primary Type: Single Use Fuses
• Series: GMT Series
• Shape: RECTANGULAR
• Standards: UL Recognized
• Termination: Plug-in
• Type: Telecommunication fuse
• Additional Information: Tin-Plated Beryllium Copper Terminal
• Height: 0.62 in
• Length: 0.78 in
• Width: 0.11 in
• ECCN: EAR99
• Material: Tin-plated beryllium copper terminal
• Rated Voltage: 125V ac/60V dc
• Fuse Amps: 0.50A
• Manufacturer: Bussmann
• MPN: GMT-1/2A
• Indicating/Non-Indicating: Non-Indicating
