Bussmann FWP-32A14F Bussmann Series FWP-32A14F 32 Amp 700 VAC Ferrule Semiconductor High Speed Fuse

Product Description

The Bussmann Series FWP-32A14F is a high-speed fuse designed for various electrical applications. This fuse operates at a maximum voltage of seven hundred VAC and comes with a current rating of thirty-two Amps. The fuse is classified under Class aR and features a ferrule end connection.

• Rated for 700 VAC (UL)
• Includes ceramic construction for durability
• Interrupt rating of 200 kAIC at 700 VAC

Product Highlights

The Bussmann Series FWP-32A14F fuse is essential for protecting circuits against overload and short circuits. It is suitable in applications like DC common bus, DC drives, and power converters. This fuse offers reliable performance in critical electronic systems.

Product Information

Standard Information

• Brand: Bussmann Mfg.
• NorthEast Part #: 140968

Technical Specifications

• Voltage Rating: 690 Volt
• Amperage Rating: 32 Amp
• End Type: Ferrule
• Material: Ceramic
• Weight: 21.2 g
• Dimensions: 0.563 inches in diameter x 2.000 inches in length
• Applications: DC Common Bus, DC Drives, Power Converters/Rectifiers, Reduced Voltage Starters
• Connection Type: Ferrule End X Ferrule End
