Bussmann FWP-125A High Speed Fuse 125 Amp 700 VAC/VDC 200 kAIC

Product Description

The Bussmann FWP-125A is a 125 Amp high-speed fuse by Bussmann Mfg. This fuse is suitable for both AC and DC applications up to 700 volts. The fuse can handle 200 kAIC interrupt ratings, making it ideal for protecting sensitive components such as diodes and SCRs. This product is non-indicating and features a cartridge body with blade end terminals.

• 125 Amp rating
• 700 VAC/VDC voltage rating
• 200 kAIC interrupt rating

Product Highlights

The Bussmann FWP-125A fuse provides excellent protection for DC drives, power converters, and reduced voltage starters. Its compact design allows for efficient thermal management, ensuring reliable operation in high-current environments.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Body Size: 1.5 inches Diameter x 5.09 inches Length
• Type: North American Style
• Mounting Type: Stud
• Material: Fiberglass
• Voltage Rating: 700 VAC/VDC
• Amperage Rating: 125 Amp
• Interrupt Rating: 200 kAIC
• Element: Single
