Bussmann FWH-250A High Speed Fuse 250A 1000 VAC/800 VDC 50/200 kA

Product Description

The Bussmann Series FWH-250A High Speed Fuse is designed for superior performance in high current applications. This fuse operates within a voltage range of 1000 VAC and 800 VDC and has a current rating of 250 Amps. It features a non-indicating, cartridge body style, and is ideal for DC common bus, DC drives, and power converters.

• Voltage: 1000 VAC, 800 VDC
• Amperage: 250 A
• Interrupt Rating: 200 kAIC

Product Highlights

This fuse delivers excellent protection for components including diodes and SCRs in various high-stress environments.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Body Size: 1.5 in Diameter x 4.34 in Length
• Element: Single
• Material: Fiberglass
• Mounting Type: Stud
• Terminal Type: Blade
• Voltage Rating: 1000 VAC/800 VDC
• Amperage Rating: 250 A
• Interrupt Rating: 50/200 kA
• Type: North American Style
