Bussmann FWH-150B Fast Acting High Speed Fuse 150 A 500 VAC 50 kA Interrupt

Product Description

The Bussmann FWH-150B is a fast acting high speed fuse designed for protecting AC and DC drives, power converters, rectifiers, and variable speed drives. With a rating of one hundred fifty amperes at five hundred volts AC and an interrupt rating of fifty kiloamperes, this fuse is reliable and efficient for various applications.

• Fast acting with a response time suited for critical applications.
• Cylindrical body design helps maximize space and improve installation.
• Non-indicating type minimizes the need for constant monitoring.

Product Highlights

This fuse features a ceramic construction and is suitable for mounting via a stud terminal. Its design allows for excellent DC performance and superior cycling capability.

Product Information

Standard Information

• Manufacturer: Eaton
• Brand: Bussmann

Technical Specifications

• Body Size: 1.156 inches diameter x 3.625 inches length
• Element: Single
• Frequency Rating: 45 to 1000 Hz
• Indicating/Non-Indicating: Non-Indicating
• Material: Ceramic
• Mounting Type: Stud
• Rejection/Non-Rejection: Non-Rejection
• Series: FWH
• Terminal Type: Blade End
• Type: Fast Acting
• Amperage Rating: 150 A
• Voltage Rating: 500 VAC
• Interrupt Rating: 50 kA
• Body Type: Cylindrical
