Bussmann FRS-R-65 600V RK TD FS

Product Description

The Bussmann FRS-R-65 is a Class RK5, time-delay, dual-element fuse designed for use in various electrical applications. With a voltage rating of six hundred volts AC and three hundred volts DC, it ensures reliable current limiting and protection. This fuse has a current rating of sixty-five amperes and is non-indicating, meaning it does not provide a visual cue of a blown fuse. The FRS-R-65 has an interrupting rating of two hundred kA at six hundred volts AC and twenty kA at three hundred volts DC, making it suitable for high-capacity environments.

• Class RK5, dual-element design
• Interrupting rating: 200 kA at 600 Vac
• Time-delay feature for better circuit protection

Product Highlights

This fuse is ideal for industrial and factory safety and security systems.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann

Technical Specifications

• MPN: FRS-R-65
• Type: Fuse
• Class: Class RK5
• Amperage Rating: 65 A
• Voltage Rating: 600 Vac; 300 Vdc
• Interrupt Rating: 200 kAIC at 600 Vac; 20 kAIC at 300 Vdc
• Response Time: 10 s at 500%
• Dimensions: 7.88 in length x 1.11 in diameter
