Bussmann FRS-R-6-1/4 Fuse Dly Time 6.25A 600 VAC/300 VDC RK5

Product Description

Bussmann FRS-R-6-1/4 is a time delay fuse designed to provide reliable protection in electrical systems. This fuse operates at a current rating of six point two five amperes and is suitable for use in both six hundred VAC and three hundred VDC systems. It has a cylindrical body constructed of fiberglass, making it durable and efficient for various applications.

• Current limiting design prevents excess current from damaging equipment.
• Features a dual element that provides accurate time delay for motor protection.
• Meets RK5 class standards for superior performance.

Product Highlights

This fuse is ideal for circuit protection in industrial and commercial electrical applications. The Bussmann FRS-R series is known for its energy-efficient dual-element construction that allows for closer sizing, thus minimizing costs associated with larger fuses and switches.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Eaton

Technical Specifications

• Type: Current Limiting
• Amperage Rating: 6.25 A
• Voltage Rating: 600 VAC/300 VDC
• Interrupt Rating: 20/200 kA
• Response Time: 10 s at 500%
• Body Size: 0.81 in Diameter x 5 in Length
• Material: Fiberglass
• Element: Dual
• Mounting Type: Holder
• Rejection/Non-Rejection: Rejection
