Bussmann FNQ-R-9 Current Limiting Time Delay Fuse 9 A 600 V 200 kAIC

Product Description

The Bussmann FNQ-R-9 is a current limiting time delay fuse with a rating of nine amperes and a voltage of six hundred volts. It is designed with a ferrule end connection and features a melamine tube construction. This fuse provides high interrupt ratings and efficient circuit protection for various applications.

• Time delay of 12 seconds at 200% for reliable operation
• Interrupt rating of 200 kAIC for high capacity protection
• Class CC rejection feature prevents incorrect installations

Product Highlights

This fuse is ideal for controlling inrush currents in transformers and is suitable for industrial control applications.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Amperage Rating: 9 A
• Voltage Rating: 600 V
• Body Size: 13/32 in diameter x 1-1/2 in length
• Interrupt Rating: 200 kAIC
• Material: Melamine
• Response Time: 12 seconds at 200%
• End Type: Ferrule
• Standard: CE, CSA, UL 248-4
