Bussmann FNQ-1/8 Fuse 0.125A

Product Description

The BUSSMANN FNQ-1/8 is an industrial and electrical fuse with time delay. Rated at 500VAC and 0.125A, this midget fuse is suitable for residential, commercial, and industrial applications, including motor control transformers and circuits with in-rush currents. It provides supplemental protection with a 10 kAIC interrupt rating at 500V AC.

• Time delay fuse
• 0.125A amperage
• 500V AC voltage rating

Product Highlights

The FNQ-1/8 fuse offers reliable circuit protection for various applications.

Product Information

Standard Information

• Brand: BUSSMANN
• Manufacturer Part Number: FNQ-1/8
• Country of Origin: MX - Mexico

Technical Specifications

• Mfr. #: FNQ-1/8
• Manufacturer: Bussmann
• Amperage: 0.125
• Voltage: 500
• Voltage Type: AC
• Poles: 1
• Frame Type: FNQ
• Application: Motor control transformers, circuits with in-rush currents
• Material: Nickel-Plated Bronze Endcap
• Fuse Interrupt Rating: 10 kAIC at 500V ac
• Rated Voltage: 500V
• Fuse Amps: 0.125A
• Ac Voltage Rating: 500V AC
• Body Material: Fiberglass
• Body Style: Cylindrical
• Class: Midget
• Compatible Fuse Block Series: Bm, Bmm, C2617, C5268, Chm, Heb, Het, Hex, Hpg, Hps, Opm-1038, Opm-Ng
• Dc Voltage Rating: Not Rated
• Diameter: 13/32"
• Element: Dual
• Equivalent Brand And Series: Bussmann Fnq, Littelfuse Flq, Mersen Atq, Power First Hc10S
• Equivalent Series: Atq, Flq, Fnq, Hc10S
• Fits Fuse Block Style: Nonrejection
• Functionally Equal To: Ferraz, Gould ATQ, Littelfuse FLQ
• Fuse Size: 1 1/2" x 13/32"
• Indicating / Nonindicating: Non Indicating
• Interrupt Rating: 10 kA @ 500V AC
• Rejection / Nonrejection: Rejection
• Series: FNQ Series
• Speed: Time Delay
• Standards: Ce, Csa Class 1422-01, Ul-248-14 Guide Jdyx
• Visual Indication: Non Indicating
