Bussmann ECSR400 BUSS ECSR400 UL CLASS RK-5 TIME DEL

Product Description

The Bussmann ECSR400 is a UL Class RK-5 time-delay current-limiting fuse with a high amperage capacity of four hundred amps. This fuse is designed for applications in AC power distribution systems, protecting circuits for motors and transformers against overloads and short circuits.

• Time-delay feature allows for a brief overload without nuisance tripping.
• Dual element design provides superior overload protection.
• Rated for six hundred volts, this fuse ensures safe operation in demanding environments.

Product Highlights

The ECSR400 fuse is suitable for use in various AC power distribution applications, providing reliable protection for feeders and branch circuits.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Edison Fuse

Technical Specifications

• Amperage: 400 Amp
• Voltage: 600 Volt
• Type: Current Limiting, Time-Delay
• Class: Class RK5
• Diameter: 2.34 Inch
• Length: 11.63 Inch
• Weight: 2.35 lb
• Interrupt Rating: 200 kAIC
