Bussmann DFJ-50 Drive Fuse 50A 1.06 Inch Diameter X 2.38 Inch Length

Product Description

The Bussmann Series DFJ-50 Drive Fuse is a high-speed fuse designed for protection in both AC and DC applications. This product operates at a voltage of up to 450 volts DC and 600 volts AC, with a quick response to overload conditions. It has an amperage rating of 50 amps and is built for high interrupt ratings of 100 kAIC. The fuse features a clip-lock connection for secure installation and is made with a durable melamine tube.

• High-speed performance for safety in electrical circuits
• Rated for 600 Vac and 450 Vdc
• Compatible with Class J applications

Product Highlights

This fuse offers excellent protection for AC and DC drives and power semi-conductor devices.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• Type: High Speed Fuse
• Amperage: 50 Amp
• Voltage: 450 Volt
• Diameter: 1.06 Inch
• Length: 2.38 Inch
• Material: Melamine
• Interrupt Rating: 100 kAIC
• Applications: Protection of AC and DC Drives, Power Semi-Conductor Devices
