Bussmann DFJ-10 Current Limiting High Speed Drive Fuse 10 A 600 VAC/450 VDC 200/100 kAIC

Product Description

The Bussmann DFJ-10 is a current limiting high-speed drive fuse designed to protect AC and DC drives and controllers. This fuse meets the NEC branch circuit protection requirements. It features the lowest I2t among branch circuit fuses, providing maximum safety for power semiconductor devices including diodes and SCRs.

• Current limiting design
• Suitable for both AC and DC applications
• Meets NEC branch circuit protection standards

Product Highlights

This fuse is easy to coordinate with variable speed drives and electric controllers. The dimensions align with standard class J, making it compatible with common fuse blocks, holders, and switches. The silver fuse element contributes to its low let-through energy, enhancing its protective capabilities.

Product Information

Standard Information

• Manufacturer: Eaton
• Brand: Bussmann
• Part Number: DFJ-10 BU

Technical Specifications

• Amperage Rating: 10 A
• Voltage Rating: 600 VAC/450 VDC
• Interrupt Rating: 200/100 kAIC
• Body Size: 0.81 in Dia x 2.25 in L
• Material: Melamine
• Mounting Type: Stud
• Class: J
• Element: Silver
• Type: Current Limiting
• Indicating/Non-Indicating: Non-Indicating
• Rejection/Non-Rejection: Non-Rejection
• Body Type: Cylindrical
