Bussmann AGC-10 Fast-Acting Ceramic Tube Fuse 10 Amp 250 V

Product Description

The Bussmann AGC-10 is a fast-acting fuse designed for electronic circuits. With a voltage rating of two hundred fifty volts and an amperage rating of ten amps, this fuse provides reliable protection for your applications. Its compact size, measuring one-fourth inch in diameter and one and one-quarter inches in length, allows it to fit in various electrical systems.

• Fast-acting performance ensures quick response to overcurrent conditions.
• Interrupt rating of ten kAIC allows for safe operation in demanding environments.
• Constructed with a glass body for visibility and reliable functionality.

Product Highlights

Ideal for electronic circuit applications, the Bussmann AGC-10 fuse is a single element, non-indicating, and non-rejection type. Its ferrule end connection makes installation straightforward.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Eaton

Technical Specifications

• Type: Electronic, Fast Acting
• Voltage Rating: 250 VAC
• Amperage Rating: 10 A
• Body Size: 1/4 in Diameter x 1-1/4 in Length
• Interrupt Rating: 200 A/10 kA
• Material: Glass
• End Type: Ferrule
• Response Time: 120/3.6k s
