Bussmann 60688 GMA Cartridge Fast Acting Fuse With Indicator 125 VAC, 6 A

Product Description

The Bussmann 60688 GMA cartridge fuse is a fast-acting fuse with an indicator designed for electronic circuits. This fuse operates at one hundred twenty-five volts AC and features an amperage of six amps. It provides reliable performance with an interrupt rating of ten thousand amps at one hundred twenty-five volts AC. The fuse is constructed with nickel-plated brass end caps and includes optional axial leads.

• Fast-acting, low breaking capacity
• Glass tube material for durability
• Meets UL, CSA, and PSE standards

Product Highlights

Product Information

Standard Information

• Brand: Bussmann
• MPN: 60688

Technical Specifications

• Amperage: 6 amps
• Series: GMA
• Type: Cartridge
• Voltage Rating: 125 VAC
• Interrupt Rating: 10 kA at 125 VAC
• Response Time: 60 min at 135%, 2 min at 200%
• Terminal: Ferrule
• Body Style: Non-Rejection Cylindrical
• Element: Single
• Material: Glass Tube
• Diameter: 5 mm
• Length: 20 mm
• Usage: For Electronic Circuits
• Nominal Resistance: 0.017 ohm
