Bussmann 16530-3 6-Pack Power Terminal Block 600 VAC/VDC 760 A

Product Description

Bussmann offers the 16530-3, a power terminal block designed for power distribution applications. This product supports both six hundred volts alternating current and six hundred volts direct current with a current rating of seven hundred sixty amps. It is a three-pole unit made from durable molded thermoplastic, ensuring reliable performance.

• Rated for six hundred VAC/VDC and seven hundred sixty A
• Three-pole terminal configuration
• Suitable for line connections from six AWG to five hundred kcmil for both copper and aluminum wires

Product Highlights

Utilized in industrial control panels, this power distribution block enhances wiring management and flexibility.

Product Information

Standard Information

• Brand: Bussmann
• MPN: 16530-3

Technical Specifications

• Type: Power Distribution Block
• Voltage Rating: 600 VAC/VDC
• Amperage Rating: 760 A
• Number of Poles: 3
• Wire Size: 6 AWG to 500 kcmil Cu/Al Line, 14 to 4 AWG Cu/Al Load
• Material: Thermoplastic
• Dimensions: 8.48 in L x 5.5 in W x 2.93 in H
• Weight: 2.62 lb
• Short Circuit Current Rating: 10 kA
• Standard Compliance: CSA, UL 1059
