Burndy YS31L Ys31-L 350MCM Cu But-Spli

Product Description

The BURNDY YS31L is a 350 kcmil copper standard barrel compression splice with an internal chamfer and tin plating. It is UL/CSA certified and suitable for up to 35kV applications. Features a red color code and a die index of 18. It is ideal for limited space applications.

• Standard Barrel Length
• Ideal For Limited Space Applications
• 18 324 die index number

Product Highlights

This copper compression splice features tin plating to reduce galvanic corrosion and resist corrosive elements. Connectors are clearly marked with color coding.

Product Information

Standard Information

• Brand: BURNDY
• Manufacturer Part Number: YS31L

Technical Specifications

• IGCC: 4669
• Type: YS-L; Standard Barrel
• Finish: Tin-Plated
• Plated: Y
• Material: COPPER
• Standard: UL 486A-486B
• Die Index: 18
• Color Code: Red
• Trade Name: HYLINK
• Application: Wire Splice
• Family group: CONNECTORS
• Manufacturer: BURNDY
• Plating Type: Tin - Electro Plated
• Product Name: YS31L; Compression Splice; 350 kcmil Cu; Standard Barrel
• Product Type: SPLICE
• Rating - KVA: 35 kV
• Voltage Rating: 35 kV
• Special Features: Features: Standard Barrel Length; Ideal For Limited Space Applications While Pro
• EU RoHS Indicator: Yes
• Voltage - Maximum: 35000
• Description - Long: 350 kcmil CU; Standard Barrel; Internal Chamfer; Tin Plated; UL/CSA; 90C; Up to
• Description - Short: 350 kcmil; CU; Standard Barrel SPLICE
• Description - Slang: SPLICE CODE STD BBL
• Feature - Barrel Type: Standard
• Dimension - B Length inch: 1.12 in
• Dimension - B Length fraction: 1-1/8 in
• Dimension - Strip Length inch: 1-3/16
• Standards - Industry Standards: UL 486A-486B
• Standards - RoHS Compliance St: CM
• Catalog Number: YS31L
• Connector Type: STANDARD BARREL
• Feature - Barrel Style: Chamfered
• Sub Brand: HYLINK
• UPC: 781810508350
• UPC 14 Digit GTIN: 00781810508350
• Dimension - L Length Overall mm: 66 mm
• Dimension - Length Overall inch: 2.60 in
• Conductor - Copper Str Compact Size: 350
• Conductor - Copper Str Size: 350 kcmil
• Conductor - Copper Str Size Range: 350 kcmil
• Conductor - Material: COPPER
• Conductor Size: 350 KCMIL
• Conductor Type: CODE
• Wire Size: 350 kcmil
• Certification - CSA Approved: Yes
• Certification - cULus: No
• Certification - ETL: No
• Certification - UL Recognized: No
• Industry Standard(s): UL 486A-486B
• Standards - Industry Standards Met: UL 486A-486B
• Standards - RoHS Compliance Status: CM
• UL Listed: Yes
• Length: 2.6 in
• Temperature Rating: 90 deg C
• Voltage: 600 to 35000 VAC
• Barrel Type: Standard
• Specifications: 1-3/16 in Strip Length
• UOM: E
