BURNDY YAZ8C2TC38 8 AWG CU Two Hole 3/8 Stud Size 1 Hole Spacing Long Barrel Inspection Window Internal Chamfer Tin Plated UL/CSA 90C Up to 35kV Red Color Code

Product Description

The Burndy YAZ8C2TC38 is a two-hole lug designed for wire termination. This product is suitable for use in various electrical applications. The lug is made from copper and features a long barrel, which allows for a secure connection. Its inspection window enables easy verification after installation.

• Rated for up to 35kV
• UL Listed for 90 degrees Celsius
• Constructed from copper with electro-tin plating

Product Highlights

This product is ideal for electrical work that requires reliability and efficiency. Its design accommodates a variety of wire sizes, ensuring compatibility across multiple applications.

Product Information

Standard Information

• Catalog Number: YAZ8C2TC38
• Manufacturer: Burndy, a Hubbell affiliate

Technical Specifications

• Voltage Rating: 35
• Material: Copper
• Application: Wire Termination
• Made in USA: Yes
• Special Features: UL Listed 90 degrees Celsius, 600V - 35kV, with inspection window
• Standard: UL 486A-486B
• Die Index: 49
• Color Code: Red
