Burndy YAZ6C2TC14E1 6 AWG CU, Two Hole, 1/4 Stud Size Long Barrel 6 AWG CU

Product Description

The Burndy YAZ6C2TC14E1 is a reliable compression terminal designed for wire termination applications. It accommodates copper conductors and is suitable for voltage ratings up to thirty-five kilovolts. This terminal features a long barrel design with an inspection window for easy verification of strip lengths and connections.

• UL and CSA approved for safety and performance.
• Temperature rating of ninety degrees Celsius for various environments.
• Compatible with a variety of crimping tools and tools sets.

Product Highlights

This product offers efficient wire termination with a long barrel and an internal chamfer that enhances performance and reliability. The design includes features to facilitate easy inspection of wire connections.

Product Information

Standard Information

• Manufacturer: Burndy, a Hubbell affiliate
• Material: Copper

Technical Specifications

• Catalog Number: YAZ6C2TC14E1
• Voltage Rating: 35 kV
• Application: Wire Termination
• Die Index: 7 or 374
• Color Code: Blue
• Wire Strip Length: 1-3/16 inches
• Pad Size: 0.45 inches W x 0.08 inches Thk
• Barrel Length: 1.12 inches
