BURNDY YA342LN 500 kcmil CU, Two Hole, 1/2 Stud Size, 1-3/4 Hole Spacing, Standard Barrel, Inspection Window, Internal Chamfer, Tin Plated, UL/CSA, 90C, Up to 35kV, Brown Color Code, 20 or 299 Die Index

Product Description

BURNDY YA342LN is a copper compression cable lug designed for wire termination applications. It accommodates a conductor size of five hundred kcmil and features a standard barrel design with an inspection window. This product is ideal for use in electrical connections where reliability is critical.

• Voltage rating of up to thirty-five kV
• UL Listed for temperature up to ninety degrees Celsius
• Constructed with electro-tin plated copper

Product Highlights

The YA342LN lug offers a reliable connection with minimal resistance, making it suitable for a variety of electrical projects.

Product Information

Standard Information

• Brand: BURNDY
• Manufacturer: Burndy, a Hubbell affiliate

Technical Specifications

• Catalog Number: YA342LN
• Material: Copper
• Voltage Rating: 35 kV
• Wire Strip Length: 1-7/16 inches
• Pad Size: 1.55 inches x 0.23 inches
• Hole Spacing: 1-3/4 inches
• Temperature Rating: 90 degrees Celsius
• Special Features: UL listed, inspection window, internal chamfer
