Burndy YA302N 300 kcmil CU Two Hole 1/2 Stud Size Long Barrel Internal Chamfer

Product Description

The Burndy YA302N is a long barrel cable lug designed for efficient wire termination. It accommodates a conductor size of 300 kcmil and features a two-hole design. This product is suitable for applications up to thirty-five kilovolts, making it a reliable choice for high-voltage projects.

• Designed for 300 kcmil copper conductors
• Voltage rating of up to 35 kV
• UL and CSA approved for enhanced safety

Product Highlights

The YA302N cable lug features tin plating for corrosion resistance and is suitable for both mechanical and hydraulic crimping tools. It is made in the USA and meets industry standards.

Product Information

Standard Information

• Manufacturer: Burndy, a Hubbell affiliate
• Catalog Number: YA302N

Technical Specifications

• Material: Copper
• Voltage Rating: 35 kV
• Temperature Rating: 90 degrees C
• Pad Size: 1.2 inches width x 0.16 inches thickness
• Pad Hole Spacing: 1-3/4 inches
• Wire Strip Length: 2 inches
• Die Index: 17/298
• Application: Wire termination
