Product Description
The Burndy YA27L2 is a compression cable lug designed for secure electrical connections. It is made from copper and is suitable for use with three-aught AWG stranded conductors. This product features a short, skived barrel with a standard straight design. The barrel length is one inch, which ensures a compact size for various applications.
- Conductor Material: Copper
- Pad Size: 0.91 inches W x 0.13 inches Thk
- Stud Size: 1/4 inch
Product Highlights
This compression cable lug is UL 467 approved and CSA listed. It has a durable design with an inspection window and chamfered cable entry, ensuring easier wire insertion.
Product Information
Standard Information
-
Manufacturer: Burndy
-
UPC: 78181055381
Technical Specifications
-
MPN: YA27L2
-
Conductor Size: 3/0 AWG Stranded
-
Barrel Type: Short, Skived, Standard, Straight
-
Overall Length: 2.04 inches
-
Die Index: 14
-
Material: Electro-Tin Plated Copper
-
Wire Strip Length: 1-1/16 inches
-
Number of Pad Holes: 1
