BURNDY YA26L2 2/0 AWG CU One Hole 1/4 Stud Size Standard Barrel Inspection Window Internal Chamfer Tin Plated UL 90 Up to 35kV

Product Description

The BURNDY YA26L2 is designed as a one-hole compression cable lug. It accommodates conductor sizes up to two American wire gauge (AWG) and features an inspection window. Manufactured to meet UL and CSA standards, this product is suitable for wire termination in various electrical applications.

• Conductor material: Copper
• Voltage rating: 35 kV
• UL Listed for 90 degrees Celsius

Product Highlights

This product is notable for its durability and reliability in heavy-duty electrical installations.

Product Information

Standard Information

• Manufacturer: Burndy, a Hubbell affiliate
• Catalog Number: YA26L2
• Country of Origin: United States
• Application: Wire Termination
• Material: Copper

Technical Specifications

• Die Index: 13
• Stud Size: 1/4 inch
• Overall Length: 1.94 inches
• Wire Strip Length: 1 inch
• Special Features: Tin plated, UL listed for up to 35 kV, inspection window
• Voltage Rating: 35 kV
• UPC: 781810553763
