BURNDY TP188FBG25 22-18INS FORK TERM

Product Description

The BURNDY TP188FBG25 is a compression fork terminal designed for electrical applications. This product accommodates conductor sizes from twenty-two AWG to eighteen AWG. It features a deep V groove design, ensuring a strong connection. The terminal is insulated with vinyl and rated for a temperature of one hundred five degrees Celsius.

• Type: Compression Fork Terminal
• Material: Electrolytic Tin Plated Copper
• Voltage Rating: 600 Volt

Product Highlights

This product is ideal for use in electrical installations where reliable connections are necessary.

Product Information

Standard Information

• Manufacturer: BURNDY
• UPC: 78181048659

Technical Specifications

• Conductor Size: Minimum 22 AWG, Maximum 18 AWG
• Stud Size: #6 to #8
• Temperature Rating: 105 Deg C
• Voltage Rating: 600 Volt
• Insulation Diameter: 0.15 Inch
• Overall Dimensions: 0.68 Inch Length x 0.31 Inch Width
• Standard Package: 25
• Approval: UL 486/467, CSA
