Burndy TP186FBG25 22-18INS Fork Term

Product Description

The Burndy TP186FBG25 is a compression fork terminal designed to connect conductors securely. This terminal is suitable for wire sizes ranging from twenty-two AWG to eighteen AWG. It features a deep V groove and long brazed seam for improved conductivity and reliability in electrical applications.

• Deep V groove design for optimal connection
• Voltage rating of 600 volts
• Meets UL 486/467 and CSA standards

Product Highlights

This terminal supports efficient electrical connections and is ideal for residential and commercial applications.

Product Information

Standard Information

• Manufacturer: Burndy
• UPC: 78181048657
• Color: Blue
• Insulation Type: Vinyl Insulated

Technical Specifications

• Minimum Conductor Size: 22 AWG
• Maximum Conductor Size: 18 AWG
• Stud Size: #6
• Temperature Rating: 105 Deg C
• Material: Electrolytic Tin Plated Copper
• Standard Package Quantity: 25
• Voltage Rating: 600 Volt
