BURNDY KA6U Aluminum Universal Terminal, 1 Hole, 14-6 AWG (Str), 1/4 Stud, 1 Screw, Al/Cu Rated

Product Description

The BURNDY KA6U is an aluminum universal terminal designed for reliable electrical connections. This terminal is suitable for both aluminum and copper conductors and meets the requirements for Al/Cu rated applications.

• Compatible with 14 to 6 AWG stranded conductors
• Constructed from high-strength aluminum alloy
• Electro tin-plated for low contact resistance

Product Highlights

Designed for ease of installation, the KA6U features a single screw connection with a torque rating of forty-five inch-pounds. It is ideal for use in a variety of electrical applications.

Product Information

Standard Information

• Manufacturer: Burndy, a Hubbell affiliate
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: KA6U
• Material: Aluminum
• Application: For Aluminum And Copper Conductors
• Number of Conductors: 1
• Stud Size: 1/4 inch
• Overall Length: 1.06 inches
• Height: 0.51 inches
• Standard Compliance: UL 486A-486B
