Burndy HSB34T300PF Heat Shrink Tubing 600V 25 Ft Reel

Product Description

The BURNDY HSB34T300PF is a heat shrink tubing, featuring a minimum expanded ID of 0.75" and a maximum recovered ID of 0.375". Constructed from thin wall polyolefin, this black tubing has a shrink ratio of 2:1 and is rated for 600V. It is provided on a 25-foot reel and suitable for use with conductors ranging from #1 AWG to #3/0 AWG.

• Heat Shrink Tubing
• 0.75" ID Min.(Exp.), 0.375" ID Max.(Rec.)
• Shrink ratio-2:1, 600V

Product Highlights

Heat shrink tubing made of thin wall polyolefin with 2:1 shrink ratio, suitable for electrical insulation and protection.

Product Information

Standard Information

• Brand: BURNDY
• Manufacturer Part Number: HSB34T300PF
• Country of Origin: China

Technical Specifications

• Catalog Number: HSB34T300PF
• Connector Type: THIN WALL REEL
• Material: Cross-linked Polyolefin
• UPC: 781810213865
• Height: 0.75 in
• Length: 25 '
• Width: 0.75 in
• Conductor Range: #1 AWG to #3/0 AWG
• Conductor Size: 1AWG - 3/0AWG
• Certification - CSA Approved: Yes
• Certification - ETL: No
• Standards - RoHS Compliance Status: CM
• UL Listed: No
• Minimum Pack Quantity: 1
• Manufacturer: Burndy
• Family Series: Burndy Shrink Tubing
• Description: 25ft.X 3/4in. BLK TW HTSHRNK
• Shape: Straight Tube
• Nom. Inner Diameter (in): 3/4 "
• Color: Black
• Shrink Ratio: 2:1
• Recovered Diameter: 0.38 "
• Operating Temperature: -131-275 °F
• Approvals: CSA
• Country of Origin: China
