Product Description
The BURNDY CL501TN is a copper lay-in lug designed for direct burial applications. This lug accommodates conductors ranging from fourteen to four American Wire Gauge and provides a secure connection for solar panel grounding. The open-faced design allows for easy installation without cutting or breaking the conductor. It is UL467 listed for direct burial in earth or concrete.
- Compatible with 14-4 AWG conductors
- Constructed from high-strength, pure electrolytic copper
- Approved for use in direct burial applications
Product Highlights
The CL501TN provides reliable performance in demanding environments.
Product Information
Standard Information
-
Brand: BURNDY
-
Manufacturer: Burndy, a Hubbell affiliate
Technical Specifications
-
Catalog Number: CL501TN
-
Material: Copper
-
Country of Origin: Canada
-
Application: For direct burial applications in concrete or earth
-
Special Features: Tin plated, UL467 listed, open-faced design
-
Stud Size: #10
-
Overall Length: 1.13 inches
-
Height: 0.85 inches
-
Tongue Width: 0.38 inches
