BURNDY BIT250FX Aluminum UNITAP Tap - Same Side Entry, #10-250 Class B & C, #10-3/0 Class G,H,I,K, DLO, 2 PORT

Product Description

The BURNDY BIT250FX is an aluminum UNITAP connector designed for secure and efficient electrical connections. This tap features a same-side entry design, accommodating conductor sizes from #10 to 250 MCM for Class B and C, as well as #10 to 3/0 for Classes G, H, I, and K, along with DLO applications. Built from AL6061-T6 aluminum, it ensures durability and performance in various electrical tasks.

• Two ports for additional connectivity.
• Oxide inhibitor included to enhance performance.
• Temperature rating up to 135 degrees Celsius.

Product Highlights

The BIT250FX provides a reliable solution for clear insulated multiple tap connections.

Product Information

Standard Information

• Catalog Number: BIT250FX
• Manufacturer: Burndy, a Hubbell affiliate
• UPC: 621945439214

Technical Specifications

• Application: Clear Insulated Multiple Tap Connectors
• Material: Aluminum
• Special Features: Clear Plastisol covered AL6061-T6 aluminum body, saves time, lowers installation costs, eliminates taping.
• Standard: UL 486A-486B
• Country of Origin: United States
• Temperature Rating: 135 degrees Celsius
• Cross Reference Products: PBTS-2-250-F
