Burndy BIBS600-8 Bibs600-4 One Sided Unitap

Product Description

The BURNDY BIBS600-8 Bibs600-4 One Sided Unitap is a multiple tap connector with a voltage rating of 600 V and 8 ports. It features a 1 side cable entry and is made from aluminum/copper conductor material. Accommodates minimum conductor size 4 AWG (Aluminum), 4 AWG Stranded (Copper) and maximum conductor size 600 KCMIL (Aluminum), 600 KCMIL Stranded (Copper).

• Multiple Tap Connector
• 600 V Voltage Rating
• 8 Ports
• UL 486B, CSA Approval
• RoHS Compatible
• 90 Deg C Temperature Rating

Product Highlights

This unitap connector is UL 486B and CSA approved and RoHS compatible. The body is made of clear plastisol covered AL6061-T6 aluminum and is suitable for use in temperatures up to 90 Deg C.

Product Information

Standard Information

• Brand: BURNDY
• Manufacturer Part Number: BIBS600-8

Technical Specifications

• Voltage Rating: 600 V
• Number of Ports: 8
• Cable Entry: 1 Side Entry
• Conductor Material: Aluminum/Copper
• Minimum Conductor Size: 4 AWG (Aluminum), 4 AWG Stranded (Copper)
• Maximum Conductor Size: 600 KCMIL (Aluminum), 600 KCMIL Stranded (Copper)
• Body Material: Clear Plastisol Covered AL6061-T6 Aluminum
• Approval: UL 486B, CSA
• RoHS Compatible: True
• Temperature Rating: 90 Deg C
• Hex Key Size: 3/8 Inch
• Number Of Screw: 8
• Manufacturer Part Number: BIBS6008
• Manufacturer: Burndy
• Product Series: UNITAP
• Description: 600-4 ONE SIDED UNITAP
• Connection Type: Push-In
• Max Voltage: 600 V
• Wire Size Range: 4 AWG-600 kcmil
• Sealant Type: Plastisol
• Material: Aluminum
• Direct Burial: No
• Approvals: CSA, UL
