Burndy BIBS46 Unitap Aluminum Multiple Tap Connector 6-Port 14-4 AWG

Product Description

The Burndy BIBS46 is a UNITAP aluminum multiple-tap connector providing six single-sided ports for indoor Al/Cu conductor terminations. It accepts run conductor sizes 14�4 AWG, is constructed of AL6061-T6 aluminum with clear plastisol insulation for visual insertion confirmation, and includes a pre-installed oxide inhibitor. The connector is rated 600 V, meets UL 486A-486B standards, and has a temperature rating of 90�C (194�F).

• Six-port, one-sided entry UNITAP connector for aluminum and stranded copper conductors (14�4 AWG).
• AL6061-T6 aluminum body with clear plastisol cover and pre-installed oxide inhibitor for visual verification and contact protection.
• Rated 600 V, meets UL 486A-486B standards; torque 45 in-lb, hex key size 1/8 in, wire strip length 5/8 in.

Product Highlights

Six-port indoor multi-tap; 14�4 AWG Al/Cu; clear plastisol; 600 V, UL 486A-486B.

Product Information

Standard Information

• Brand: BURNDY
• Manufacturer Part Number: BIBS46
• Country of Origin: United States

Technical Specifications

• Brand: Burndy
• Manufacturer Part Number: BIBS46
• Series: UNITAP
• Connector Type: Multiple tap (multi tap)
• Number of Ports: 6
• Entry Type: One-sided entry
• Material: Aluminum (AL6061-T6)
• Insulation Type: Plastisol (clear)
• Conductor Size Range: 14�4 AWG
• Conductor Type: Aluminum and stranded copper
• Voltage Rating: 600 V
• Temperature Rating: 90�C (194�F)
• Standards/Approvals: UL 486A-486B; CSA; RoHS compliant (as noted)
• Hex Key Size: 1/8 in
• Torque: 45 in-lb
• Wire Strip Length: 5/8 in
• Oxide Inhibitor: Pre-installed
• Number of Screws: 6
• Plating: Unplated
• Dimensions: 2.83 in L x 1.25 in W x 1.25 in H
• Weight: 0.16 lb
• Country of Origin: United States
• Application/Use: For indoor use only
• UPC: 781810223840
• GTIN: 00781810223840
