Burndy BIBS2/05 Multi-Tap, Al/Cu Rated

Product Description

The BURNDY BIBS2/05 is a clear plastisol covered, single side entry, 5-port multi-tap connector, Al/Cu Rated for #14-2/0 AWG. The AL6061-T6 aluminum body saves time, lowers installation costs, and eliminates taping. Oxide inhibitor is pre-installed, inhibiting moisture and contaminants from entering the contact area. Its range-taking capability reduces the number of connectors necessary in inventory.

• Clear Plastisol covered AL6061-T6 aluminum body saves times and lowers installation costs and eliminates taping
• Clear plastisol allows visual confirmation that conductor is properly inserted
• Oxide inhibitor pre-installed inhibits moisture and contaminants from entering the contact area

Product Highlights

The BURNDY BIBS2/05 multi-tap connector features a clear plastisol cover, single-side entry, and is Al/Cu rated.

Product Information

Standard Information

• Brand: BURNDY
• Manufacturer Part Number: BIBS2/05
• Country of Origin: US - United States

Technical Specifications

• Catalog Number: BIBS2/05
• Connector Type: Multi Tap
• Hex Key: 3/16
• Insulation: Y
• Insulation Type: Plastisol
• Material: Aluminum
• Material - Hardware: Aluminum
• Number Of Ports: 5
• Physical Attribute - Number of Screws: 5
• Physical Attribute - Screw Type: Allen
• Plated: N
• Plating Type: Unplated
• Temperature Rating: 194
• Trade Name: UNITAP
• UPC: 781810223901
• UPC 14 Digit GTIN: 00781810223901
• Voltage - Maximum: 600 V
• Conductor - AL Str Size: 8 AWG;6 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 AWG;2/0 AWG
• Conductor - AL Str Size Range: 8 AWG-2/0 AWG
• Conductor - Copper Str Size: 14 AWG;12 AWG;10 AWG;9 AWG;8 AWG;7 AWG;6 AWG;5 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 ;2/0 Str
• Conductor - Copper Str Size Range: 14 AWG - 2/0 AWG
• Conductor Size: 14-2/0 AWG
• Conductor Type: AL C Str-Size CU C Str-Size
• Certification - CSA Approved: Yes
• Certification - cULus: No
• Certification - ETL: No
• Certification - UL Listed Direct Burial: No
• Certification - UL Recognized: No
• Industry Standard(s): UL 486A-486B
• Standards - Industry Standards Met: UL 486A-486B
• Standards - RoHS Compliance Status: CM
• UL Listed: Yes
• Finish: Tin-Plated
• Insulation Material: Plastisol
• No. of Ports: 5
• Voltage: 600 Volt
• Brand: Hubbell Incorporated
• Sub Brand: Burndy
• Weight: 0.2300 lb
• Height: 1.38 Inch
• Length: 3.53 Inch
• Overall Length: 3.53 in
• Width: 1.31 in
• CSA: Yes
• Volts AC: 600
• Standards: California Proposition 65
• Wire/Cable Openings: 5
