BURNDY AMS500 Aluminum Mechanical Splice 500 kcmil-3/0 AWG

Product Description

The BURNDY AMS500 is an aluminum mechanical splice designed for use with copper and aluminum conductors. This product features a dual rating, making it suitable for various applications. The splice includes four screws and a hex size of three-eighths inches, providing secure connections. It is constructed from high-strength, tin-plated aluminum.

• Compatible with 500 kcmil to 3/0 AWG conductors
• Features large screw diameters for better contact
• Meets ANSI C119.4 standard requirements

Product Highlights

This splice is effective for joining copper and aluminum conductors, ensuring low contact resistance and preventing galvanic corrosion.

Product Information

Standard Information

• Manufacturer: Burndy, a Hubbell affiliate
• Country of Origin: United States

Technical Specifications

• Catalog Number: AMS500
• Application: For use with copper and aluminum conductors
• Material: Aluminum
• Number of Screws: 4
• Hex Size: 3/8 inch
• Screw Diameter: 13/16 inch
• Temperature Rating: 194 degrees Fahrenheit
• UPC: 781810241059
