BURNDY 1PLD6003 Al Distribution Tap Connectors, UV Black Plastisol Covered, 3 Ports, Double Sided Entry, 4-600 kcmil

Product Description

The BURNDY 1PLD6003 Al Distribution Tap Connector is suitable for connecting copper or stranded aluminum wires. This connector features a UV rated plastisol cover. It accommodates conductor sizes ranging from #4 to 600 kcmil and offers a voltage rating of 600 volts. This unit is designed for double-sided entry and features three ports for versatile connections.

• Double-sided entry design with three ports.
• Rated for indoor and UV exposure applications.
• Torque rating of 375 in-lbs for secure connections.

Product Highlights

Designed for effective wire connections, this tap connector is made from aluminum and is suitable for various applications.

Product Information

Standard Information

• Manufacturer: Burndy, a Hubbell affiliate
• Country of Origin: United States

Technical Specifications

• Catalog Number: 1PLD6003
• Application: For indoor use only, copper or stranded aluminum
• Material: Aluminum
• Temperature Rating: 90 degrees Celsius
• Conductor Size Range: 4 AWG - 600 KCMIL
• Number of Ports: 3
• Wire Strip Length: 1-1/8 inches
• Special Features: UV rated plastisol cover, oxide inhibitor pre-installed, UL486B listed.
