BURNDY 1PLD3504 Al Distribution Tap Connectors 600 V 4 Ports

Product Description

The BURNDY 1PLD3504 is an aluminum distribution tap connector designed for secure electrical connections. It features four ports with double-sided entry, accommodating conductor sizes from ten AWG to three hundred fifty kcmil. This product is suitable for use in indoor environments and is designed for copper or stranded aluminum conductors.

• Four ports for multiple connections
• Torque rating of two hundred seventy-five inch-pounds
• Temperature rating of ninety degrees Celsius

Product Highlights

This tap connector includes features such as a UV rated plastisol covering and an aluminum body that minimizes the need for taping. The oxide inhibitor pre-installed helps prevent moisture and contaminants from entering the connection area, ensuring reliability.

Product Information

Standard Information

• Brand: BURNDY
• Manufacturer: Burndy, a Hubbell affiliate

Technical Specifications

• Catalog Number: 1PLD3504
• Country of Origin: United States
• Material: Aluminum
• Special Features: UV rated elastomer cover, multi-port capabilities, oxide inhibitor
• Conductor Size Range: 10 AWG - 350 KCMIL
• Torque Rating: 275 in-lbs
• Wire Strip Length: 1-1/8 inches
• Number of Ports: 4
• Temperature Rating: 194 Degrees F
• Cross Reference Products: PBTD-4-350, IPLD350-4
