BURNDY 1PLD2/03 UV Rated Black UNITAP 3 #14 - 2/0 2.19 in L 1.56 in.

Product Description

The BURNDY 1PLD2/03 is a UV rated Black UNITAP designed for reliable wire connections. Suitable for 14 to 2/0 AWG conductors, it is made from AL6061-T6 Aluminum. This product features a unique double wire entry to accommodate two wires, making it versatile for various installations.

• Designed for indoor use with copper or stranded aluminum wires
• UL486B listed for safety and reliability
• UV rated plastisol insulation protects against environmental factors

Product Highlights

This UNITAP simplifies installation by reducing the need for additional taping. It incorporates an oxide inhibitor that prevents moisture from affecting connection quality, enhancing longevity.

Product Information

Standard Information

• Brand: BURNDY
• Manufacturer: Burndy, a Hubbell affiliate

Technical Specifications

• Catalog Number: 1PLD2/03
• Material: Aluminum
• Application: For indoor use only, Copper or stranded aluminum
• Country of Origin: United States
• Temperature Rating: 194 Degrees F
• Special Features: UV rated plastisol covered, oxide inhibitor pre-installed, torque rated for 120 in-lb, three ports
• Conductor Size: 14 - 2/0 AWG
• Hex Size (key): 3/16 in
