Bullard 53313 Type 1 Cut-off Wheel 3in Metal 24 Grit

Product Description

The BULLARD 53313 is a Type 1 small-diameter cut-off wheel engineered for metal cutting on both electric and pneumatic angle grinders. Measuring 3 inches in diameter with a 1/16-inch thickness and a 3/8-inch arbor bore, this wheel operates at a maximum rated speed of 25,450 RPM. The 24-grit aluminum oxide bond delivers fast, straight cuts through metal and sheet metal with minimal deflection. Sold in a box quantity, the 53313 is a dependable choice for HVAC, pipefitting, fabrication, and general metal trades where consistent cut-off performance is required across varied materials.

The BULLARD 53313 is suited for cutting ferrous metals, sheet metal, conduit, pipe, and structural steel in both shop and field applications. Its compact 3-inch diameter makes it well-matched for tight-access grinder work, including cutting in confined mechanical spaces, electrical conduit trimming, and HVAC duct framing. The wheel is compatible with standard small-diameter electric and air-powered die grinders and angle grinders fitted with the appropriate 3/8-inch arbor. Residential and light commercial trade professionals will find the thin 1/16-inch kerf reduces material loss and heat buildup during cuts.

Key Features

• Type 1 flat profile for straight, controlled cut-off work
• 3-inch diameter x 1/16-inch thickness for a narrow kerf and reduced heat
• 3/8-inch arbor bore fits standard small-diameter grinder spindles
• 25,450 RPM maximum operating speed rated for electric and air grinders
• 24-grit construction for aggressive cutting on metal and sheet metal
• Packaged in a box quantity for job-site stocking and replenishment

Compatibility

Designed for use with small-diameter electric and air-powered grinders accepting a 3/8-inch arbor bore and rated at or above 25,450 RPM. Suitable for cutting metal and sheet metal applications.

Installation Notes

Installation and wheel changes must be performed by a qualified tradesperson with the grinder fully disconnected from power or the air supply before mounting. Inspect the wheel for cracks or chips before each use and never exceed the rated maximum RPM of 25,450. Always use the manufacturer-supplied arbor nut and flange for mounting and wear appropriate PPE including a face shield, gloves, and hearing protection during operation. Applicable ANSI B7.1 safety standards for the use, care, and protection of abrasive wheels should be followed.

Technical Specifications

• Wheel Type: Type 1
• Diameter: 3 inches
• Thickness: 1/16 inch
• Arbor Bore: 3/8 inch
• Grit: 24
• Maximum RPM: 25,450 RPM
• Application: Metal, Sheet Metal
• Package Weight: 2.15 pounds
• Unit of Measure: Box

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 53313
