Bullard 28569 Turbo Pipeline Grinding Wheel Type 27

Product Description

The BULLARD 28569 is a Type 27 depressed center turbo pipeline grinding wheel built for combination cutting and light grinding in a single pass. The wheel measures 5 inches in diameter with a 1/4 inch thickness and a 5/8-11 arbor hole, and it is rated for a maximum of 12200 RPM. Designed for pipeline and metal fabrication work, it allows the operator to cut and grind in the same application without switching wheels or tools. The turbo design promotes smooth material removal and better control under demanding service conditions. It weighs 0.7 pounds and is sold individually.

This wheel is suited for metal grinding and light cut-off tasks common in pipeline fabrication, structural steel work, and field welding applications. The Type 27 depressed center profile provides the clearance needed for flush and angle grinding in tight or confined weld zones. It is a practical choice for pipefitters, ironworkers, and welding professionals who need a single wheel to handle both operations on a job site or in a fabrication shop.

Key Features

• Turbo design enables combination cutting and light grinding without changing wheels
• Type 27 depressed center profile for flush and angle grinding access
• 5 inch diameter with 1/4 inch thickness and 5/8-11 arbor fitment
• 12200 RPM maximum speed rating for compatibility with standard angle grinders
• Long life metal grinding formulation for extended wheel service

Compatibility

Designed as a replacement or service wheel for standard 5 inch Type 27 angle grinders with a 5/8-11 spindle thread, commonly used in pipeline, structural, and metal fabrication applications.

Installation Notes

Wheel mounting and use should be performed by a qualified tradesperson familiar with angle grinder safety per ANSI B7.1 and applicable worksite standards. Inspect the wheel for cracks or damage before each use and never operate above the rated 12200 RPM. Ensure the grinder guard is properly installed before running the wheel. Always wear appropriate PPE including a face shield, gloves, and hearing protection during grinding operations.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Diameter: 5 inches
• Thickness: 1/4 inch
• Arbor Size: 5/8-11
• Maximum RPM: 12200 RPM
• Weight: 0.7 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 10

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 28569
