Bullard 28563 Type 27 Turbo Pipeline Grinding Wheel

Product Description

The BULLARD 28563 is a Type 27 depressed center turbo pipeline wheel designed for combination cutting and light grinding in a single operation. Built for metal fast grinding at up to 12200 RPM, this wheel fits a 5/8-11 arbor and measures 5 inches in diameter with a 1/4 inch thickness. It is intended for trade professionals who need a single wheel to handle both cutting and light grinding passes without swapping tooling. The turbo design delivers smooth material removal and precise control in demanding pipeline and fabrication environments.

This wheel is suited for pipeline work, metal fabrication, and structural steel applications where switching between cut-off and grinding wheels wastes time. The Type 27 depressed center profile keeps the wheel body below the work surface plane, allowing flush and angle grinding passes. It is a practical choice for pipefitters, ironworkers, welders, and general metalworkers who run high-cycle grinding tasks in the field or shop. Minimum order quantity is 10 units per purchase.

Key Features

• Combination cutting and light grinding in a single wheel eliminates mid-job tool changes
• Type 27 depressed center geometry provides flush grinding access and improved operator control
• Rated to 12200 RPM for use with standard 4-1/2 to 5 inch angle grinders
• 5/8-11 arbor thread fits the most common angle grinder spindle standard
• Turbo pipeline design delivers smooth grind finish on metal pipe and structural stock

Compatibility

Designed as an OEM-style replacement-grade abrasive wheel for use with angle grinders accepting a 5/8-11 threaded arbor and rated for Type 27 depressed center wheels up to 12200 RPM.

Installation Notes

Installation and wheel changes must be performed by qualified personnel following ANSI B7.1 safe-use guidelines for abrasive wheels. Power down and disconnect the grinder from its power source before mounting or removing any wheel. Inspect the wheel for cracks or damage before each use and never exceed the rated maximum RPM marked on the wheel. Wear appropriate PPE including face shield, gloves, and hearing protection during operation.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Diameter: 5 inches
• Thickness: 1/4 inch
• Arbor Size: 5/8-11
• Maximum RPM: 12200 RPM
• Application: Metal Fast Grind
• Weight: 0.6 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 10

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 28563
