Bullard 28467 Turbo Pipeline Grinding Wheel 4.5in Type 27

Product Description

The BULLARD 28467 is a Type 27 depressed center turbo pipeline wheel engineered for combination cutting and light grinding in a single pass. Measuring 4.5 inches in diameter with a 0.25-inch thickness and a 5/8-11 arbor, this wheel mounts directly to standard angle grinders used in metal fabrication and pipeline work. The 24 GRT grit rating delivers aggressive stock removal while the turbo segment geometry maintains surface control during light grinding passes. Fabricators and pipefitters use this wheel to eliminate mid-job tool changes, keeping workflow moving on demanding weld prep and cut-off tasks.

The 28467 is designed for metal fast-grind applications, particularly pipeline fabrication and structural steel work where a single wheel must handle both cutting and blending operations. It is suited for use on carbon steel, pipe joints, and structural weld areas where switching between a cut-off wheel and a grinding wheel would otherwise slow production. The Type 27 depressed center profile allows flush grinding in tight access areas common to pipe work. Minimum order quantity is 10 wheels per unit.

Key Features

• Type 27 depressed center design allows flush, controlled grinding in confined pipeline joints
• Turbo segment geometry enables combination cutting and light grinding without changing wheels
• 24 GRT grit provides aggressive fast-grind action on carbon steel and structural metal
• 5/8-11 arbor fits standard angle grinders used in pipefitting and fabrication trades
• Compact 4.5-inch diameter suits hand-held angle grinder use in tight work areas

Compatibility

Designed as an OEM-style replacement or direct-use consumable for standard 4.5-inch angle grinders equipped with a 5/8-11 spindle thread, commonly used in metal pipeline fabrication and structural steel applications.

Installation Notes

Mounting and replacement of grinding wheels should be performed by qualified personnel following ANSI B7.1 safety standards. Inspect the wheel for cracks or chips before each use and verify the grinder guard is in place before operation. Always confirm the grinder spindle speed does not exceed the maximum rated RPM marked on the wheel. Wear appropriate PPE including a face shield, gloves, and hearing protection during operation.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Diameter: 4.5 inches
• Thickness: 0.25 inches
• Arbor Size: 5/8-11
• Grit: 24 GRT
• Application: Metal Fast Grind
• Weight: 0.5 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 10

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 28467
