Bullard 24669 Type 27 Grinding Wheel 6x1/4x7/8 Turbo Metal

Product Description

The BULLARD 24669 is a Type 27 depressed center grinding wheel designed for metal removal and long-life grinding applications. Built in a turbo profile, this 6 inch wheel delivers aggressive stock removal while maintaining wheel integrity at speeds up to 10200 RPM. The 1/4 inch thickness and 7/8 inch arbor bore make it a direct fit for standard angle grinders used in fabrication, construction, and maintenance work. Licensed tradespeople and metal fabricators rely on this wheel for demanding cuts and surface preparation on ferrous metals.

This grinding wheel is suited for residential and commercial metal fabrication, structural steel work, pipe preparation, and weld grinding. The Type 27 depressed center design allows flat and edge grinding in tight spaces and on flush surfaces. It is sold in a box quantity of 25, making it practical for shop stocking or job-site supply. Metal workers, ironworkers, pipefitters, and general contractors commonly use this wheel on heavy-duty angle grinders for sustained grinding cycles.

Key Features

• Type 27 depressed center profile allows flush and flat surface grinding
• Turbo segment design promotes faster material removal on metal
• Rated to 10200 RPM for use with standard 6 inch angle grinders
• 1/4 inch wheel thickness provides durability for long-life grinding applications
• 7/8 inch arbor bore fits common angle grinder spindles
• Sold in a box of 25 for shop or job-site stocking

Compatibility

Designed as an OEM-style replacement grinding wheel for use with standard 6 inch angle grinders accepting a 7/8 inch arbor bore and rated for Type 27 depressed center wheels.

Installation Notes

Mounting and wheel changes must be performed with the grinder fully powered down and disconnected from its power source. Always inspect the wheel for cracks or chips before mounting and verify the tool RPM rating meets or exceeds the wheel maximum of 10200 RPM. Use the correct flange and locking nut for a Type 27 wheel and confirm the arbor bore seats properly before operation. Grinding wheel installation and use should follow ANSI B7.1 safety standards and any applicable site safety requirements.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Profile: Turbo
• Diameter: 6 inches
• Thickness: 1/4 inch
• Arbor Bore: 7/8 inch
• Maximum RPM: 10200 RPM
• Application: Metal Long Life Grind
• Box Quantity: 25
• Unit of Measure: Each

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 24669
