Bullard 24569 Turbo Pipeline Grinding Wheel 5 Inch Type 27

Product Description

The BULLARD 24569 is a Type 27 depressed center turbo pipeline wheel engineered for combination cutting and light grinding in a single pass. Built for metal applications, it runs at a maximum of 12200 RPM and mounts on a 5-inch diameter arbor configuration with a 1/4-inch thickness and a 7/8-inch arbor bore. Designed for trade professionals who work in pipeline and structural fabrication environments, this wheel reduces downtime by eliminating the need to swap between cutting and grinding wheels during the same job. The long-life construction maintains material removal rates across extended use cycles.

The 24569 is suited for light grinding and cut-off work on metal pipe and structural steel in both field and shop environments. Its turbo segment geometry delivers a smoother grind surface and improved operator control compared to standard flat grinding wheels, making it a practical choice for pipeline welders, ironworkers, and fabricators who need consistent results in demanding overhead or positional grinding applications. Sold individually; minimum order quantity is 25 units per order.

Key Features

• Type 27 depressed center profile allows flush grinding and positional cutting in tight weld joint areas
• Turbo segment design provides smooth grind finish and enhanced operator control on pipe
• Combination cutting and light grinding capability eliminates mid-job wheel changes
• Rated to 12200 RPM maximum operating speed
• Long-life metal bonding compound extends wheel service life in continuous-use environments
• 5-inch diameter with 1/4-inch thickness and 7/8-inch arbor bore for standard angle grinder fitment

Compatibility

Designed as an OEM-style replacement and standard fitment for 5-inch Type 27 angle grinders used in pipeline, fabrication, and structural metal grinding applications.

Installation Notes

Mounting and use of abrasive grinding wheels should be performed by qualified personnel following ANSI B7.1 safety standards for the use, care, and protection of abrasive wheels. Always inspect the wheel for cracks or damage before mounting, and ensure the grinder spindle speed does not exceed the 12200 RPM rating marked on the wheel. Secure the arbor nut firmly using the correct flange and wrench before operation, and always wear appropriate face and eye protection. Never use a wheel that has been dropped or shows visible damage.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Diameter: 5 inches
• Thickness: 1/4 inch
• Arbor Bore: 7/8 inch
• Maximum RPM: 12200 RPM
• Application: Metal Long Life Grinding and Cutting
• Weight: 0.45 pounds
• Sold As: Each
• Minimum Order Quantity: 25

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 24569
