Bullard 24453 Turbo Pipeline Grinding Wheel Type 27

Product Description

The BULLARD 24453 is a Type 27 depressed center turbo pipeline wheel designed for combination cutting and light grinding in a single application. Built for metal fast grind work, it runs at a maximum of 15000 RPM and measures 4 inches in diameter with a 3/16 inch thickness and a 5/8 inch arbor hole. This wheel eliminates the need to swap tools mid-job, giving fabricators and pipefitters a smooth grind with consistent control. Weighing just 0.2 pounds, it is lightweight enough for extended overhead or positional work without adding fatigue.

This wheel is suited for pipeline fabrication and maintenance environments where both cutting and light grinding are required in the same pass. The turbo-style design delivers improved stock removal while maintaining surface control, making it a practical choice for field work on carbon steel pipe and structural metal. It is typically used by welders, ironworkers, and pipefitters working in industrial, commercial, and heavy construction settings.

Key Features

• Type 27 depressed center profile for grinding and cut-off work in a single wheel
• Turbo pipeline design allows combination cutting and light grinding without changing wheels
• Maximum operating speed of 15000 RPM
• 4 inch diameter with 3/16 inch thickness and 5/8 inch arbor for standard angle grinder compatibility
• Delivers smooth grind finish with excellent tool control in demanding pipeline applications
• Lightweight at 0.2 pounds for reduced operator fatigue during extended use

Compatibility

Designed as an OEM-style replacement or direct-use Type 27 depressed center grinding wheel for standard angle grinders accepting a 5/8 inch arbor.

Installation Notes

Installation and mounting of grinding wheels should be performed by a qualified operator following ANSI B7.1 safety standards. Always verify the tool's rated RPM meets or exceeds the wheel's 15000 RPM maximum before mounting. Power down and disconnect the grinder before changing wheels, and inspect the wheel for cracks or damage before each use. Never exceed the rated maximum operating speed marked on the wheel.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Diameter: 4 inches
• Thickness: 3/16 inches
• Arbor Size: 5/8 inches
• Maximum Operating Speed: 15000 RPM
• Application: Metal Fast Grind
• Weight: 0.2 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 25

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 24453
