Bullard 23467 Turbo Pipeline Grinding Wheel 4 X 1/4 X 3/8 Inch

Product Description

The BULLARD 23467 is a Type 27 depressed center turbo pipeline wheel designed for combination cutting and light grinding in a single application. Built for metal work at a maximum speed of 15000 RPM, this wheel measures 4 x 1/4 x 3/8 inches and is engineered to eliminate wheel changes mid-task. The turbo design delivers smooth grinding action with consistent control, making it well-suited for demanding pipeline and fabrication environments where efficiency and surface quality both matter. Licensed tradespeople working in metal fabrication, pipefitting, and structural welding rely on this style of wheel for fast, controlled material removal.

This wheel is intended for use on angle grinders in metal pipeline fabrication and light grinding applications. The Type 27 depressed center profile allows the user to work close to surfaces and into tight joint areas. It handles fast grind operations where both cutting and surface blending are required without switching tools. Typical users include pipefitters, ironworkers, welders, and metal fabricators working in both shop and field conditions.

Key Features

• Type 27 depressed center profile for close-to-surface grinding and cutting
• Turbo pipeline design enables combination cutting and light grinding in one wheel
• Maximum operating speed of 15000 RPM
• 4 x 1/4 x 3/8 inch dimensions for use on standard angle grinders
• Smooth grind performance with excellent operator control in pipeline applications
• Eliminates the need to swap wheels or tools mid-application

Compatibility

Designed as an OEM-style replacement grinding wheel for angle grinders accepting Type 27 depressed center wheels with a 3/8 inch arbor and 4 inch diameter.

Installation Notes

Installation and wheel changes must be performed by a qualified tradesperson with the grinder fully powered down and unplugged or isolated from its power source. Verify that the grinder's rated RPM meets or exceeds the 15000 RPM maximum speed rating of this wheel before mounting. Always inspect the wheel for cracks or damage before use and confirm the arbor size matches. Follow ANSI B7.1 safety standards and wear appropriate PPE including face shield and gloves during grinding operations.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Diameter: 4 inches
• Thickness: 1/4 inch
• Arbor Size: 3/8 inch
• Maximum Speed: 15000 RPM
• Application: Metal Fast Grind, Pipeline Cutting and Grinding
• Weight: 0.3 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 25

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 23467
