Bullard 20969 Turbo Pipeline Grinding Wheel 9 in Type 27

Product Description

The BULLARD 20969 is a Type 27 depressed-center turbo pipeline wheel built for combination cutting and light grinding in a single application. Rated at 6500 RPM and sized at 9 x 1/4 x 7/8 inches, it handles demanding pipeline work without requiring a wheel or tool change mid-job. The long-life metal bond construction delivers consistent stock removal and smooth surface finish across the cut. Licensed tradespeople working on pipeline fabrication, structural steel, and heavy weld dressing will find this wheel well-suited to the physical demands of the work.

The BULLARD 20969 is designed for pipeline and structural metal grinding applications where a technician needs to switch between cutting and light grinding without interrupting workflow. The Type 27 depressed-center profile provides clearance and control in tight or angled positions. This wheel suits professional ironworkers, pipefitters, and welders working in field and shop environments on ferrous metal stock.

Key Features

• Type 27 depressed-center design provides clearance for grinding and cut-off in a single pass
• Turbo pipeline construction eliminates the need to swap wheels between cutting and light grinding tasks
• Rated at 6500 RPM for compatibility with standard angle grinders
• Long-life metal bond delivers extended service life on ferrous pipeline and structural material
• 9 x 1/4 x 7/8 inch dimensions fit standard large-diameter angle grinder arbors

Compatibility

Designed as an OEM-style replacement and standard-fit Type 27 depressed-center grinding wheel for 9-inch angle grinders with a 7/8-inch arbor.

Installation Notes

Installation and wheel changes must be performed by qualified personnel following ANSI B7.1 safe-use requirements for abrasive wheels. Power down and disconnect the grinder from its power source before mounting or removing the wheel. Inspect the wheel for cracks or chips before each use and confirm the grinder RPM rating meets or exceeds the 6500 RPM wheel rating. Always use the guard supplied with the grinder and wear appropriate PPE including a face shield and gloves.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Diameter: 9 inches
• Thickness: 1/4 inches
• Arbor Size: 7/8 inches
• Maximum RPM: 6500 RPM
• Application: Metal Long Life Grinding and Cutting
• Weight: 1.4 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 25

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 20969
