Bullard 20761 Turbo Pipeline Type 27 Grinding Wheel

Product Description

The BULLARD 20761 is a Type 27 depressed center turbo pipeline grinding wheel rated at 8500 RPM and sized at 7 inches diameter by 0.25 inches thickness by 0.875 inches arbor bore. It is engineered for combination cutting and light grinding in a single operation on metal pipe and structural steel. The turbo-style design delivers a smooth grind with precise control in demanding pipeline and fabrication environments. Licensed tradespeople including pipefitters, welders, and ironworkers reach for this wheel when switching tools mid-task is not practical.

This wheel is suited for light grinding and cut-off work on metal in pipeline construction, maintenance, and field fabrication applications. The Type 27 depressed center profile allows clearance in tight joint areas, making it practical for both shop and on-site use. Its fast-grind characteristic reduces dwell time on each pass, which matters in production or time-sensitive repair scenarios where a single wheel needs to handle multiple tasks without a tool change.

Key Features

• Type 27 depressed center profile for clearance in tight joint and weld areas
• Turbo design enables combination cutting and light grinding in one wheel
• 8500 RPM maximum operating speed for compatibility with standard angle grinders
• 7 inches diameter with 0.25 inch thickness and 0.875 inch arbor bore
• Fast-grind formulation reduces material removal time on metal surfaces
• Eliminates wheel changes between cutting and grinding tasks on pipeline work

Compatibility

Designed as an OEM-style replacement or direct-use Type 27 depressed center wheel for standard 7-inch angle grinders used in metal pipeline and structural fabrication applications.

Installation Notes

Installation of grinding wheels must be performed by qualified personnel following ANSI B7.1 safety requirements for the use, care, and protection of abrasive wheels. Always ensure the grinder is powered off and unplugged before mounting or removing a wheel. Verify that the grinder spindle speed meets or exceeds the wheel maximum RPM rating before operation. Inspect the wheel for cracks or chips before each use and never exceed the rated 8500 RPM.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Diameter: 7 inches
• Thickness: 0.25 inches
• Arbor Bore: 0.875 inches
• Maximum RPM: 8500
• Application: Metal Fast Grind
• Weight: 0.85 pounds
• Sold As: Each
• Minimum Order Quantity: 25

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 20761
