Bullard 14948 Type 27 Turbo Pipeline Cutoff Wheel 9 in

Product Description

The BULLARD 14948 is a Type 27 depressed-center Turbo Pipeline wheel engineered for combination cutting and light grinding in a single pass. Measuring 9 inches in diameter with a 5/32-inch thickness and a 5/8-11 threaded arbor, this wheel mounts directly to standard angle grinders rated up to 6500 RPM. The Turbo profile delivers smooth stock removal and precise control, making it a practical choice for pipeline and structural fabrication work where switching between a cutoff wheel and a grinding wheel slows the job down.

This wheel is built for demanding pipeline applications where both cutting and light grinding are required in the same workflow. It is suited for use on carbon steel pipe, structural steel, and similar ferrous materials commonly encountered in pipefitting, welding, and general fabrication. The depressed-center Type 27 geometry provides clearance for flush and near-flush work, and the 5/8-11 arbor fits the majority of 9-inch angle grinders used in the trade. Minimum order quantity is 10 wheels per order.

Key Features

• Type 27 depressed-center profile allows flush and near-flush cutting and grinding
• Turbo Pipeline design handles combination cutting and light grinding without a wheel change
• 9-inch diameter with 5/32-inch thickness balances aggression and control
• 5/8-11 threaded arbor fits standard 9-inch angle grinders
• 6500 RPM maximum rated speed
• Smooth grind finish with excellent operator control in pipeline applications

Compatibility

Designed for use on standard 9-inch angle grinders with a 5/8-11 spindle thread. Suitable for pipeline fabrication, structural steel cutting, and light grinding applications on ferrous materials.

Installation Notes

Mounting and operation of abrasive cutoff and grinding wheels should be performed by qualified tradespeople familiar with ANSI B7.1 safety requirements for abrasive wheels. Inspect the wheel for cracks or damage before each use and never exceed the 6500 RPM maximum speed rating of the wheel or the rated speed of the grinder, whichever is lower. Ensure the grinder guard is properly installed before operating. Do not use this wheel for side grinding beyond the light grinding applications it is rated for.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Diameter: 9 inches
• Thickness: 5/32 inches
• Arbor Size: 5/8-11
• Maximum Speed: 6500 RPM
• Weight: 1.25 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 10

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 14948
