Bullard 14567 Turbo Pipeline Grinding Cutting Wheel

Product Description

The BULLARD 14567 is a Type 27 depressed center turbo pipeline wheel engineered for combination cutting and light grinding in a single application. Built with premium zirconia abrasive, it delivers consistent stock removal and a smooth grind finish without requiring a wheel change between operations. Rated at 12200 RPM, it measures 5 inches in diameter with a 1/4 inch thickness and a 7/8 inch arbor bore. It is suited for pipe fabricators, pipefitters, and welders who need one wheel to handle both cut-off and light grinding passes on pipeline work.

This wheel is designed for pipeline applications where switching between cutting and grinding wheels slows down the job. The Type 27 depressed center profile provides clearance for flush and bevel work on pipe joints. It is appropriate for use in both field and shop environments, typically mounted on a 5 inch angle grinder. The zirconia abrasive construction makes it a practical choice for carbon steel and stainless steel pipeline work where control and finish quality matter.

Key Features

• Type 27 depressed center design allows flush grinding and cutting access on pipe
• Premium zirconia abrasive for extended wheel life and consistent cut performance
• Combination cutting and light grinding capability eliminates mid-job wheel changes
• 12200 RPM maximum operating speed rated for standard 5 inch angle grinders
• 7/8 inch arbor bore fits common angle grinder spindle configurations
• 1/4 inch thickness provides rigidity for controlled light grinding passes

Compatibility

Designed as an OEM-style replacement grinding and cutting wheel for use on 5 inch angle grinders with a 7/8 inch arbor spindle and a maximum tool speed rating of 12200 RPM or higher.

Installation Notes

Mounting and use of abrasive wheels should be performed by qualified personnel following ANSI B7.1 safety standards for the use, care, and protection of abrasive wheels. Always confirm the grinder is rated at or above the wheel's maximum RPM before mounting. Power down and disconnect the tool before changing wheels, and inspect the wheel for cracks or damage prior to each use. Never exceed the marked maximum operating speed.

Technical Specifications

• Wheel Type: Type 27 Depressed Center
• Abrasive Material: Premium Zirconia
• Diameter: 5 inches
• Thickness: 1/4 inch
• Arbor Bore: 7/8 inch
• Maximum RPM: 12200 RPM
• Weight: 0.45 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 25

Standard Information

• Brand: BULLARD
• Manufacturer Part Number: 14567
