Bsc Preferred LK4420BF1UFRKBLK Bi-level Bottle Filling Station

Product Description

The BSC PREFERRED LK4420BF1UFRKBLK is a bi-level outdoor bottle filling and drinking fountain station built for high-traffic public environments. Constructed from heavy-gauge type-316 stainless steel, this pedestal unit houses two filling stations and a front bubbler on each level, activated by a mechanical button system that requires no electrical connection. A chrome-plated hood guard shields the bubblers from airborne contaminants and vandal interference. The laminar flow outlet delivers a smooth, arch-free fill stream that reduces splash and improves bottle-fill accuracy. The unit ships at 176 pounds and stands 64 inches tall with a 31-inch width and 14-inch depth.

This station is designed for outdoor installation in parks, school campuses, recreational facilities, and similar public-access environments. The freeze-resistant construction allows year-round operation in cold climates without the need for heat tape or electrical winterization equipment. The fully sealed internal water system minimizes the risk of groundwater contamination. The black powder-coat finish provides a clean, neutral appearance that integrates into a wide range of outdoor site designs. Installation is typically handled by a licensed plumber connecting to a standard potable water supply line.

Key Features

• Bi-level pedestal design accommodates two simultaneous fill stations for users of varying heights
• Type-316 stainless steel construction resists corrosion, heavy use, and vandalism
• Mechanical activation requires no electrical supply, reducing installation complexity
• Freeze-resistant design supports year-round outdoor use in cold climates
• Laminar flow bottle filler produces a smooth, splash-free stream for efficient filling
• NSF 372 compliant, meeting lead-reduction requirements for public potable water fixtures
• Chrome-plated hood guard protects bubblers from contamination and misuse

Compatibility

Designed as a self-contained outdoor drinking and bottle-filling pedestal unit connecting to a standard potable cold-water supply line. No specific model family restrictions are stated by the manufacturer for this unit.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and IPC requirements. Shut off the water supply to the service line before making any connections. Do not install in locations where the water supply line cannot be isolated and drained for service. Verify that the mounting surface and anchor point are rated for the unit weight of 176 pounds prior to securing the pedestal base.
