Bryant RR15QWTR Receptacle Duplex Tamper-Resistant 15A 125V Quick Thread replacement RR15QW

Product Description

The BRYANT RR15QWTR is a duplex tamper-resistant receptacle with a 15A and 125V rating, featuring a quick thread design. This residential grade receptacle is 2-pole, 3-wire grounding, and has a NEMA rating of 5-15R. It is suitable for indoor dry environments unless protected by additional means.

• Smooth indented face appearance
• Tough thermoplastic ultrasonically welded cover and base
• Elongated strap with continuous plaster ears to secure device

Product Highlights

This tamper-resistant receptacle offers push and side wire connectivity and is UL Listed and CSA Certified.

Product Information

Standard Information

• Brand: BRYANT
• Manufacturer Part Number: RR15QWTR
• Country of Origin: China

Technical Specifications

• Product Name: Bryant Receptacle Duplex Tamper-Resistant 15A 125V Quick Thread White (RR15QWTR)
• Brand: Bryant
• SKU: RR15QWTR
• Mfr. Part Number: RR15QWTR
• Housing Color: White
• UPC Code: #883778301612
• Country of Origin: China
• Width: 1.600 in
• Performance: Environmental - Operating temperature - -20 00b0C to 60 00b0C;Mechanical - Terminal - Terminal screws accepts up to #12 AWG, Push wire designed for #14 AWG solid copper wire only
• Application: Residential Receptacles
• Environmental Conditions: Indoor Dry Unless Protected By Additional Means
• Number of Poles: 2-Pole
• Phase: Single Phase
• Standard: CSA Certified;UL Listed E2186
• Wattage: 1875
• Voltage Rating: 125 VAC
• Connectivity: Push and Side Wire
• Nema Rating: 5-15R
• Number Of Wires: 3-Wire Grounding
• Image Actual Or Representative: A
• Replaced Catalog Number: RR15QW
• Current Rating: 15 A
• Base Unit of Measure: EA
• Industry Standard(s): CSA Certified;UL Listed E2186
• Amperage Rating: 15 A
• Special Features: Tamper Resistant- Self Grounding, Quick Thread
• Wire Size: #14 AWG to #12 AWG
• Display Size: Standard Sized Product
• Description - Invoice: RCPT, DUP, TR, 15A 125V, QCK-PLT, WH
• Harmonization Code: 8536698000
• MSDS Flag: No
• Material - Mounting Hardware: Screw Mounting
• Material: Thermoplastic
• Certifications: EU RoHS Indicator
